Filter Astralpool Berlin 750 With Selector Valve
ref: 06FI00543
- Swimming pool filter series Berlin de Astralpool
- Code 00543
- Diameter 750mm
- Filter made with simultaneous resin and fibreglass projection
- 230 mm top cover
- INCLUDING 2" 6-WAY SELECTOR VALVE
- With pressure gauge, manual air and water venting
€1,352.00
IVA included
Free shipping
Technical characteristics
what type of pool is the astralpool Berlin d.750 filter suitable for?
For private pools up to 120 m3
The Berlin filters are available in diameters ranging from 500 mm to 1200 mm, so they can be installed in large-volume private pools. Sand filters wound in polyester resin and fibreglass.
General technical characteristics Astalpool Berlin filter
- Ø 240 bolt-on cover, injected for diameters up to 900 mm. Ø 400 screw-on lid in polyester and fibreglass for Ø 1050 and Ø 1200 mm.
- Satin blue finish, with dust protection by means of a "flash" of transparent polyurethane varnish, for Ø 500, Ø 600, Ø 750 and Ø 900. Blue finish for Ø 1050 and Ø 1200.
- Fitted with manifolds and diffuser in unalterable plastic materials PVC and PP.
- Fitted with pressure gauge and manual air and water drain. For Ø 900, Ø 1050 and Ø 1200 models, it incorporates a 2" sand trap.
- 6 (+1) way side selector valve for filtration, washing, rinsing, recirculation, emptying and shut-off operations on Ø 500, Ø 600 and Ø 750 models.
- Maximum filtration speed: 50 m3/h/m2.
- Maximum working pressure: 2.5 kg/cm2.
- Inner lining in HDPE (polyethylene), blown for Ø 500 and Ø 600 mm, thermoformed ABS for Ø 500 and Ø 600 mm, thermoformed ABS for Ø 600 mm
- Ø 600 mm, thermoformed ABS for Ø 750 and Ø 900 mm, polyester and fibreglass for Ø 1050 mm
- and fibreglass for Ø 1050 and Ø 1200.
- Filter base made of plastic for models up to 750 mm diameter and polyester and fibreglass for larger diameters.
Delivery contents
- Filter Astralpool Berlin d. 750
- 2" selector valve
- Instruction manual
- Pressure gauge and manual air and water purge
Dimensions of swimming pool filter Astralpool Berlin
Data Sheet
- Recommended pool size
- 80-120 m3
- Filter diameter
- 750 mm
- For pumps
- 1.5 HP
- Valve
- Side 2
- Sand load (kg)
- 250 - 300 kg
- Material
- Polyester winding
- Type of filtration
- Sand
