High-flow delivery / suction nozzle
ref: 03BO41520
ean13: 8432611138964
sku: 41520
- High flow delivery / suction nozzle max. 30 m3/h
- Cod. 41520
- The grille holes do not exceed 8 mm according to EN 13451-1 standard.
- PVC body, ABS grille, PA flange and screws AISI 304.
- Jet inclined at 30º adjustable through 360º.
- Connection for Ø75 or Ø90 pipe.
€51.90
IVA included
Technical characteristics
Nozzle Astralpool 41520
Delivery nozzle for high flow rates.
Can also be used as suction nozzle.
- PVC body, ABS grille, PA flange and AISI 304 screws.
- Grille holes do not exceed 8 mm according to EN 13451-1 standard.
-Maximum flow rate delivery 30m3/h for a maximum flow velocity of 4 m/s according to EN 13451-1.
- Maximum flow rate suction 5m3/h for a maximum flow velocity of 0.5 m/s according to EN 13451-1.
- Jet inclined at 30º adjustable 360º.
- Connection for Ø75 or Ø90 pipe.
Data Sheet
- Coating
- Concrete
- Manufactured in
- Plastic
- Type of accessory
- Discharge nozzle
