Automatic selector valve Lateral 2" System VRAC III

2" selector valve

New and improved automatic selector valve with keypad and push-buttons for manoeuvres. Control of filtration, washing, rinsing and emptying.

• Adaptability: Adapts to all sand filter installations and is quick and easy to install.
• Comfort: Easy programming through its keypad, with all the automated information about the filtration of your pool.
• Healthy water: To obtain better water quality, filtration can be daily, optimising the washing cycles.
• Safety: The automatic valve continuously monitors the filtration system, thus avoiding possible incidents.
• Information is easy to read through its LEDs.

Equipped with an integrated programmer keyboard with which we can access to perform the following operations:

• Filtration: It starts up when it receives the order from a timer installed in the control panel or any other externally programmed order.
• Washing: It enters automatically by pressure switch signal, with optional weekly washing frequency, i.e. by time and pressure switch.
• Rinsing: It is carried out automatically after each wash.
• Emptying: This is carried out by means of the push button, which positions the valve and must be confirmed via the control cabinet. This feature prevents accidental emptying.
• New flushing push button and informative LED.
• Includes MODBUS communications protocol for operation and supervision.

The automatic selector valve "System VRAC III" is easily adaptable to any filter on the market and its assembly is quick and easy.

An attractive design will enhance the appearance of your technical room giving it an air of modernity. The technology incorporated in these valves will also save you time and allow you to enjoy your pool more.

Features Valve 70769:

• Innovative design.
• Easy installation.
• Low weight and volume.
• High impact resistant cover.
• Water and dust resistant (IP 65).
• Complies with CE regulations.
• Self-stopping of the pump when the valve is changing position.
• Hydraulic safety valve: Optional safety system against possible power failures which may coincide with
• power failure that may coincide with a change of position.

Advantages System VRAC III

Increased valve torque due to more powerful electronics. New flushing button with LED on the control panel, which makes it easier to start the flushing routine and adjust the pressure switch. Programmed times are retained in memory in case of power loss.
Automatic internal temperature control to avoid condensation. MODBUS communication system allows the valve to be controlled and monitored from a central control.
New error coding, including error of 3 consecutive flushes, to prevent accidental emptying of the pool. Time lag times have been included to avoid water hammer.

NOTE

Installation of the Multiport Safety Valve is recommended.

what is Fluidra Connect?

Fluidra Connect is the intelligent solution that allows the pool to be controlled remotely by the end user and/or the professional. It gives you the possibility to diagnose, manage and control all your installations from a computer screen.

Fluidra Connect allows two control modes:

• Basic and intuitive control for the end user via the App.
• Advanced control for the professional through the platform www.fluidraconnect.com

what do I need to install it in my pool?

There are 3 options:

1) CONNECT BOX. For Fluidra Connect compatible products, the Connect Box is the brain of the pool. Any installation to be managed via Fluidra Connect requires a Connect Box that must be connected to the internet via WiFi or cable.

2) GPIO. For products that are not compatible with Fluidra Connect, this device offers a solution with 4 outputs and 4 digital inputs. The GPIO allows us to make ON/OFF and time programming on non-compatible products. It also allows us to see the status of certain devices.

3) FLUIDRA CONNECT COMPATIBLE COMMUNICATION KIT. Some products allow the installation of this kit to become compatible with Fluidra Connect.
