Exactus Manual Dosing Pump 20 L/H 5 BAR

Dosing pump Astralpool Exactus

Metering pumps are a type of pump whose purpose is to inject a liquid (in swimming pools it is normal to inject a liquid reducing agent, ph increaser or liquid chlorine) into a fluid line. There are two types of dosing pumps: peristaltic pumps and diaphragm pumps. There are also models that allow you to control the parameter of the product you are dosing, i.e. control the pH level or control the chlorine level.

The Exactus range of dosing pumps Astralpool have a manually adjustable flow rate with a potentiometer, which determines the frequency of the injections. Adjustable from 0 to 100%.

There is also the possibility of a more precise flow regulation at low frequencies.

Technical characteristics of the Exactus Manual dosing pump.

• Flow rate manually adjustable by potentiometer.
• Flow rate of 20 lts/h.
• Pressure: 5 BAR.
• Equipment complies with CE standards. IP-65 protection.

• Electrical connection 220/240 V 50/60 Hz. Materials in contact with the liquid: polypropylene, viton and teflon.
• Control panel protection with transparent polycarbonate cover and corresponding gaskets
• Anti-humidity touch display.
• Built-in drain valve.
• No lubrication required, minimum maintenance.
• Pump head: PP (polypropylene)
• Diaphragm: PTFE (Teflon)
• Valves: Lip valve FPM (viton)

Box contents:

• Exactus Manual dosing pump 20L/H 5 BAR
• Complete suction filter (PP-FPM viton),
• Injection valve (PP-FPM viton)
• Suction/impulsion hose 2m + 2m PVC;
• 2m PE distribution hose.
• Support (foot-wall)
