QR1T control cabinet for spas
ref: 04ARQR1T
- Electric panels for the protection and control of spas and baths.
- For 1 pump with 1 piezo push button and 1 timer
- Suitable for single-phase pumps 230V and max. 3 hp
- Suitable for installation in installations with: cannons, counter-current swimming, waterfalls, blower pumps, jets, hydromassage pumps, etc..
€599.91
IVA included
Free shipping
Technical characteristics
QR1T enclosure
It is an electrical cabinet for the protection and control of spas and bathtubs. They are also suitable for installation in installations with: cannons, counter-current swimming, waterfalls, blower pumps, jets, hydromassage pumps, etc.
This cabinet is suitable for single-phase 230 V II pumps, max. 3 HP with submersible pushbutton and PZT equipment (electronic controller for submersible pushbuttons). The PZT controller has a timer function. When pressed, the output is activated for the set time (0-30 minutes). If pressed earlier, the output is deactivated. When the controller is set to 0, it functions as a switch.
Dimensions: 180 x 225 x 135 mm.
