Variable speed pool pump Espa Noxplus 1 CV

ESPA Noxplus variable speed pump

ESPA Noxplus is the pool pump that incorporates the frequency inverter with an important innovation in its operation to adapt the set to the pool application: the variation of speeds in the work cycles.

Backwash system that, thanks to a specifically developed cycle, manages to increase the efficiency of the process while shortening the cleaning time, drastically reducing the amount of water consumed and achieving an efficient cleaning.

Ultra-quiet (45 dB)

Longer service life

Energy and economic savings

Up to 5 years warranty

Main characteristics

MATERIALS

• Motor housing: aluminum
• Mechanical seal: alumina-graphite
• Suction body: technopolymer
• Enclosing body: technopolymer
• Discharge body: technopolymer
• Diffuser: technopolymer
• Motor shaft: stainless steel AISI-431
• Impeller: technopolymer
• Seals: NBR/EPDM
• Pre-filter: technopolymer

EQUIPMENT INCLUDED

• Suction and discharge connectors Ø50 mm
• Two meters of cable

CONSTRUCTION FEATURES

• Suction diameter: Ø50 mm
• Impulsion diameter: Ø50 mm
• Sealing: by mechanical seal
• Motor cooling: fan
• Type of suction connection: push-in fitting
• Type of discharge connection: push-in fitting

ELECTRICAL CHARACTERISTICS

• Electrical insulation: Class F
• Service factor: S1
• Degree of protection: IPX5
• Reset: automatic
• Motor type: asynchronous

LIMITS OF USE

• Maximum suction: 4 meters
• Maximum liquid temperature: 40ºC
