Variable speed pool pump Espa Noxplus 1 CV
ref: 05BO214856
sku: 214856
- Noxplus Variable Speed Pump
- Manufacturer: ESPA
- Power: 1 CV
- Single-phase current
- Hydraulic and economical saving
- Ultrasilent
- Ideal to replace the old SILEN and the current NOX 75/100/150 (same measures)
€699.00
IVA included
Free shipping
Technical characteristics
ESPA Noxplus variable speed pump
ESPA Noxplus is the pool pump that incorporates the frequency inverter with an important innovation in its operation to adapt the set to the pool application: the variation of speeds in the work cycles.
Backwash system that, thanks to a specifically developed cycle, manages to increase the efficiency of the process while shortening the cleaning time, drastically reducing the amount of water consumed and achieving an efficient cleaning.
Ultra-quiet (45 dB)
Longer service life
Energy and economic savings
Up to 5 years warranty
Main characteristics
MATERIALS
- Motor housing: aluminum
- Mechanical seal: alumina-graphite
- Suction body: technopolymer
- Enclosing body: technopolymer
- Discharge body: technopolymer
- Diffuser: technopolymer
- Motor shaft: stainless steel AISI-431
- Impeller: technopolymer
- Seals: NBR/EPDM
- Pre-filter: technopolymer
EQUIPMENT INCLUDED
- Suction and discharge connectors Ø50 mm
- Two meters of cable
CONSTRUCTION FEATURES
- Suction diameter: Ø50 mm
- Impulsion diameter: Ø50 mm
- Sealing: by mechanical seal
- Motor cooling: fan
- Type of suction connection: push-in fitting
- Type of discharge connection: push-in fitting
ELECTRICAL CHARACTERISTICS
- Electrical insulation: Class F
- Service factor: S1
- Degree of protection: IPX5
- Reset: automatic
- Motor type: asynchronous
LIMITS OF USE
- Maximum suction: 4 meters
- Maximum liquid temperature: 40ºC
Data Sheet
- Type of current
- Single-phase 220V
- For Filters
- 500mm-600mm
- Brand
- Espa
- Variable Speed
- Yes
- Power (hp)
- 1 CV
